- Size: 270 stere
- Place of Origin: Shandong China
- Brand Name: Jinliang
- Model Number: QTZ63 (PT5610)
- Weight: 32000.000 kg
Model:QTZ63 (PT5610) Loading capacity Performance | ||||||||||||||
JIB/BOOM | Fall | Max.Load | 14 | 16 | 20 | 26 | 30 | 32 | 36 | 42 | 48 | 54 | 56 | |
m | t | |||||||||||||
56 | 4 Falls | 12.9 | 6 | 5.49 | 4.74 | 3.69 | 2.72 | 2.29 | 2.12 | 1.83 | 1.49 | 1.25 | 1.05 | 1.00 |
2 Falls | 24.15 | 3 | 3.00 | 3.00 | 3.00 | 2.72 | 2.29 | 2.12 | 1.83 | 1.49 | 1.25 | 1.05 | 1.00 | |
54 | 4 Falls | 13.27 | 6 | 5.66 | 4.89 | 3.81 | 2.82 | 2.37 | 2.19 | 1.89 | 1.55 | 1.30 | 1.10 | |
2 Falls | 24.84 | 3 | 3.00 | 3.00 | 3.00 | 2.82 | 2.37 | 2.19 | 1.89 | 1.55 | 1.30 | 1.10 | ||
48 | 4 Falls | 14.38 | 6 | 6.00 | 5.34 | 4.17 | 3.09 | 2.61 | 2.42 | 2.09 | 1.72 | 1.45 | ||
2 Falls | 26.92 | 3 | 3.00 | 3.00 | 3.00 | 3.00 | 2.61 | 2.42 | 2.09 | 1.72 | 1.45 | |||
42 | 4 Falls | 16.14 | 6 | 6.00 | 6.00 | 4.74 | 3.53 | 2.99 | 2.78 | 2.41 | 2.00 | |||
2 Falls | 30.21 | 3 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 2.78 | 2.41 | 2.00 | ||||
36 | 4 Falls | 17.71 | 6 | 6.00 | 6.00 | 5.28 | 3.93 | 3.39 | 3.10 | 2.70 | ||||
2 Falls | 33.1 | 3 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 2.70 | |||||
Model:QTZ63 (PT5610) Hoisting Technical Performance | |||||||||
Hoisting Mechanism | Hoisting Speed | Fall | α=2 | α=4 | |||||
Detailed Speed | M/min | / | 38 | 74 | / | 20 | 38 | ||
t | 3 | 1.5 | 6 | 3 | |||||
Slewing Mechanism | Slewing Speed | M/min | 0.64 | ||||||
Trolleying Mechanism | Trolleying Speed | R/min | 40/22 | ||||||
Total Power | k kw w | 40.2 | |||||||
