- Size: 270 stere
- Place of Origin: Shandong China
- Brand Name: Jinliang
- Model Number: QTZ80 (TC5513)
- Weight: 32000.000 kg
Model:QTZ80 (TC5513) Loading capacity Performance | |||||||||||||||||||
Jib/ Boom Radius | 3～13.2 | 20 | 24 | 29 | 30 | 32 | 35 | 38 | |||||||||||
Load Capacity (t) | 2Fall | 3.185 | 3.069 | 2.818 | 2.514 | 2.258 | |||||||||||||
4Fall | 8 | 5.012 | 4.040 | 3.203 | 3.069 | 2.826 | 2.514 | 2.251 | |||||||||||
Jib/ Boom Radius | 40 | 45 | 48 | 50 | 55 | ||||||||||||||
Load Capacity (t) | 2Fall | 2.108 | 1.793 | 1.635 | 1.540 | 1.334 | |||||||||||||
4Fall | 2.098 | 1.774 | 1.612 | 1.515 | 1.303 | ||||||||||||||
Model:QTZ80 (TC5513) Hoisting Technical Performance | |||||||||||||||||||
Hoisting Mechanism | Hoisting Speed | Fall | / | α=2 | α=4 | ||||||||||||||
Speed | m/min | / | 41.05 | 80.36 | / | 20.11 | 39.37 | ||||||||||||
Corresponding Max Loadiing | t | / | 4 | 2 | / | 8 | 4 | ||||||||||||
Power | kw | 30/30 | |||||||||||||||||
Slewing Mechanism | Slewing Speed | r/min | 0.64 | ||||||||||||||||
Power | kw | 3.7×2 | |||||||||||||||||
Trolleying Mechanism | Trolleying Speed | m/min | 22/44 | ||||||||||||||||
Power | kw | 3/4.5 | |||||||||||||||||
Jacking Mechanism | Jacking Speed | m/min | 0.4 | ||||||||||||||||
Power | kw | 5.5 | |||||||||||||||||
Total Power | kw | 47.7 | |||||||||||||||||
